Emerson Climate Technology Outdoor unit Wiring Diagram

You can see Wiring Diagram of Emerson Climate Technology Outdoor unit this Diagram will help you to solve fault and you can make wiring connection easy. this diagram in color wires and original from Emerson Climate Technology Outdoor unit.

Emerson Climate Technology Outdoor unit wiring diagram

Unit Operating Setting After Installation

you should do 3 setting After installation of Emerson climate technology Unit and you can see setting below

3 Settings Name :

1 : RTC Setting (Real Time Clock)

2 : Refrigerant Setting

3 : Evaporator Temperature Setting (ZXD only)

Setting buttons and Display Panel

setting display of emerson climate technology unit
RTC setting of emerson climate
Refrigerant Setting of Emerson climate
Evaporator temperature Setting of Emerson climate
