Fully4world is a Platform for free learning about RAC and HVAC Fault Solutions, AC Error Codes, AC diagrams, Refrigerator diagrams, Compressor HP codes, HVAC jobs, AC Jobs, Refrigerator and AC jobs,
Mostly errors in air conditioner Solve full details, Error codes list and solutions
Hello Friends is post mai apko koch error cods dekhny ko mily gy ye wo error cods hai jo mostaly ac mai ajaty hai kis b model mai ajaty hai ye error to ap nichy image mai tumam error cods dekh sakty hai or un ky agy in ka fault b btaya hai ky kon sa error kis fault pr ata hai umeed hai k apko pahly ki trha ye post b achi lgi hogi or apky liay ye post bohot helpful sabit ho ge …
Error
Description
FA
Error with oil temperature sensor 1 (Fixed-frequency)
Fb
Error with oil temperature sensor 2 (digital)
Fc
High-pressure valve error
Fd
Low-pressure valve error
F0
Indoor Ambient temperature sensor error
F1
Indoor Tube-Inlet sensor error
F2
Indoor Tube-middle sensor error
F3
Indoor Tube-exit sensor error
F4
Outdoor Ambient temperature sensor error
F5
Outdoor Tube-Inlet sensor error
F6
Outdoor Tube-middle sensor error
F7
Outdoor Tube-exit sensor error
F8
Error with exhaust temperature sensor 1 (Fixed-frequency)
F9
Error with exhaust temperature sensor 2 (digital)
E1
High-pressure protection
E2
Prevention against low temperature
E3
Low-pressure protection
E4
Exhaust over temperature
E5
Over current Protector
E6
Communication error
Eb
Water full protection (cassette)
Mostly in Inverter AC Indoor we face these error codes
Error
Description
E0
EEPROM parameter error
E1
Communication malfunction between indoor to outdoor unit
E2
Zero-crossing signal error
E3
Indoor fan speed out of control
E5
Open or short circuit of outdoor temperature sensor
E6
Open or short circuit of room or evaporator coil temperature sensor
P0
Inverter Module protection
P1
Over voltage or too low voltage protection (<120v or >400v)
P2
Temperature protection of compressor top (120/105 °C)
