Pel AC Error Codes for Basic/Mid/high End inverter
August 2, 2021
In this Post you can see Pel AC Error Codes , Pel AC Error Codes for Basic/Mid/high End inverter
| Error Codes | Faults |
|---|---|
| E1 | Room Temperature Sensor Fault |
| E2 | Outdoor Coil Temperature Sensor Fault |
| E3 | Indoor Coil Temperature Sensor Fault |
| E4 | Indoor Fan Motor or DC Motor feedback fault |
| E5 | Indoor and Outdoor Communication Fault |
| F0 | Outdoor DC Fan Motor Fault |
| F1 | IPM modular Fault |
| F2 | PFC modular Fault |
| F3 | Compressor Operation Fault |
| F4 | Exhaust Temperature Sensor Fault |
| F5 | Compressor Top Cover Protection |
| F6 | Outdoor ambient Temperature Fault |
| F7 | Over/Under Voltage Protection |
| F8 | Outdoor Modular Communication Fault |
| F9 | Outdoor EEPROOM Fault |
| FA | Suction Temperature Sensor Fault (4-Way Valve Switch failure) |
