Refrigerator is useful Product for Every home And this product used in every home. Sometimes it contains an error code. We can fix some error codes at home and we need to call a technician to fix some error codes. In this post you will find all the error codes of Bosch Refrigerator and I hope you will benefit a lot from this post. If you find it helpful, please share this post.

Error CodesSolution
E01Fridge compartment Sensor break / short circuit.
E02Freezer compartment Sensor break / short circuit.
E03Temperature-controlled drawer temperature sensor is defective.
E04Malfunctions in the condenser temperature sensor of the freezer.
E06Fridge evaporator sensor No failure message during normal operation. After auto diagnostic test, E06 is displayed, if evaporator sensor fails.
E07Freezer evaporator sensor. No failure message during normal operation. After auto diagnostic test, E07 is displayed, if evaporator sensor fails.
E10Power module software failure.
E11Display module software failure.
E15Ambient Sensor break / short circuit.
E20Communication error between power and display module.
E21Communication error between display control module and the ice and water dispenser control module.
DOOROPENWhen the door remains open for longer 30 s.
LOWPOWERNot working, until the voltage is above 85 V US / 165 V EU.

Bosch Icemaker Fault Display

If an error code occurs do the following control according to the following action list.

Error CodesProblem
1 1 1Ice production cycle is interrupted.
1 2 1Ice production cycle is interrupted.
1 3 1Ice production cycle is interrupted.
1 4 1Ice tray heater or icemaker electronic is faulty.
2 1 1Sensor fault in ice maker
2 2 1Sensor fault in ice maker.
2 3 1Internal ice maker fault.
2 4 1Self Test Failed as Door was open.
3 1 1Internal ice maker fault
3 1 2Icemaker motor faulty
3 1 3Water valve of icemaker faulty
3 1 4Ice tray heater is faulty.
3 1 5Icemaker inlet water heater problem.
3 2 1Internal ice maker fault
3 2 2Icemaker motor faulty
3 2 3Water valve of icemaker faulty
3 2 4Ice tray heater is faulty.
3 2 5Icemaker inlet water heater problem.
3 3 2Internal ice maker fault
3 3 3Internal ice maker fault
3 3 4Internal ice maker fault
3 3 5Internal ice maker fault
3 4 2Internal ice maker fault
3 4 3Internal ice maker fault
3 4 4Internal ice maker fault
3 4 5Internal ice maker fault
4 1 1Internal ice maker fault
4 2 1Internal ice maker fault
5 1 1Main voltage is to high. Check main voltage
5 2 1Main voltage is to low. Check main voltage
5 3 1Internal ice maker fault
5 4 1Internal ice maker fault
5 5 1Internal ice maker fault

Cleaning

The Crisper Drawers and Chiller Drawer can be removed for cleaning.

  1. Unplug the appliance or turn off the circuit breaker.
  2. Remove all food from the appliance and store in a cool location.
  3. Clean the appliance with a soft cloth, using lukewarm water and a small amount of pH-balanced dishwashing liquid.
  4. Rub dry when done.
  5. Wipe the door seal with clear water only and then thoroughly wipe dry.
  6. After cleaning, reconnect to switch on the appliance.

If you use a refrigerator, you must protect and care for your refrigerator so that your refrigerator performs well in cooling.
The refrigerator should be placed in a place where there is ventilation (ventilation mean = Air Crossing).
If you want to read more about Bosch refrigerators, download the PDF file from the link below. You will find a lot Information in this PDF file.
